Материнська плата ASUS P5LD2-VM Intel 945G, s775

Материнська плата ASUS P5LD2-VM Intel 945G, s775

Характеристики:

- Intel 945G chipset
- Intel LGA775 Pentium 4 CPU
- Intel® Core™2 Extreme / Core™2 Duo Ready
- Dual-Core CPU Support
- Intel Graphics Media Accelerator 950
- DDR2 667/533
- Intel Gb LAN
- 64-bit CPU support

• CPU
  LGA775 socket for Intel® Core™2 Extreme / Core™2 Duo / Pentium® D / Pentium® 4 / Celeron® D Processors
  Intel® EM64T / EIST / Hyper-Threading Technology

  *Only PCB R2.0(or higher) support Intel® Core™2 processor
• Chipset
  Intel 945G
  Intel ICH7
• Front Side Bus
  1066/800/533 MHz
• Memory
  4 x DIMM, max. 4GB, DDR2 667 / 533, non-ECC, un-buffered memory
  Dual Channel Architecture
  * Due to general PC architecture, a small amount of memory is reserved for system usage and thus the actual memory size is less than the stated amount.
• Expansion Slots
  1 x PCI-E x16
  1 x PCI-E x1
  2 x PCI
  PCI 2.2
• VGA
  Intel Graphics Media Accelerator 950
• Storage/RAID
  Intel ICH7 South Bridge:
  1 x UltraDMA 100/66/33
  4 x Serial ATA 300/150
  ITE IDE controler:
  1x UltraDMA 133/100
• Audio
  Realtek ALC 882, 8-ch High-Definition Audio CODEC
  S/PDIF out interface
• LAN
  Intel Gb LAN
• USB
  8 USB2.0 ports
• Other ASUS Special Features
  ASUS AI Overclocking
  ASUS EZ Flash
  ASUS MyLogo2
  ASUS C.P.R.
  ASUS Q-Fan
  ASUS CrashFree BIOS 2
• Back Panel I/O Ports
  1 x Parallel
  1 x Serial
  1 x PS/2 Keyboard
  1 x PS/2 Mouse
  1 x VGA
  1 x Audio I/O
  1 x RJ45
  4 x USB
• Internal I/O Connectors
  2 x USB connectors supports additional 4 USB ports
  CPU / Chassis FAN connectors
  24-pin EATX Power connector
  4-pin ATX 12V Power connector
  Chassis Intrusion connector
  S/PDIF out connector
  CD audio in
  3-pin PWR FAN connector
  Front panel High Definition Audio connector
• Manageability
  WfM 2.0,DMI 2.0,WOL by PME, PXE, RPL, Chassis Intrusion, SM Bus
• Support Disc
  Drivers
  ASUS PC Probe II
  Anti-Virus Software
  ASUS LiveUpdate
• Accessories
  User's manual
  UltraDMA cable
  IDE cable
  FDD cable
  I/O shield
  SATA cables
