Материнська плата MSI PM8M2-V, s775

CPU

• Supports Intel® Pentium 4 / Celeron D processors in LGA775 package.
• Supports up to Pentium 4 5XX, 6XX and Celeron D 3xx sequence processor.
• Support Intel 04B and 04A processors.
• Supports Intel Hyper-Threading technology.
• Supports up to 3.8GHz, FSB@800/533MHz
Please refer to CPU Support for compatible CPU; the above description is for reference only.

Chipset

• VIA® P4M800 Chipset
 - 64-bit P4 processor FSB 800MHz
 - 64-bit DDR DRAM memory DDR 333/400MHz
 - 32-bit AGP (66MHz) for 8x/4x mode
 - Supports 8X V-Link

• VIA® VT8237R Chipset
 - Integrated Direct Sound AC'97 audio.
 - Dual channel Ultra DMA 33/66/100/133 master mode EIDE controller.
 - Integrated USB 2.0 controller.
 - ACPI & PC2001 compliant enhanced power management


Main Memory

• Supports four memory banks using two 184-pin DDR DIMM.
• Supports up to 2GB DDR333/400 DRAM.
• Supports 2.5v DDR DRAM.


Slots

• One AGP (Accelerated Graphics Port) 8x/4X slot.
• Two PCI 2.2 32-bit PCI bus slots (support 3.3V/5V PCI bus interface).


On-Board IDE

• An IDE controller on the VT8237R chipset provides IDE HDD/CD-ROM with PIO, Bus Master and Ultra DMA133/100/66 operation modes.
- Can connect up to four IDE devices.

• Serial ATA/150 controller integrated in VT8237R.
- Up to 150MB/sec transfer rate.
- Can connect up to 2 Serial ATA drives.
- Supports RAID 0, 1 and RAID 0+1

Video

• S3 UniChrome Pro integrated graphics


Audio

• AC'97 link controller integrated in VIA® VT8237R
• Realtek ALC655 2/6 channel S/W audio codec.
 - Compliance with AC'97 v2.2 spec.
 - Meets PC2001 audio performance requirement.


LAN

• Realtek 8201CL
 - Integrated Fast Ethernet PHY.
 - Supports 10Mb/s and 100Mb/s auto-negotation operation.
 - Compliance with PCI v2.2 and PC99 standard.
 - Supports ACPI power management.


Internal I/O Connectors

 - ATX 20-Pin power connector
 - 4-pin ATX 12V power connector
 - CPU / System / Power connectors
 - CD-in connector
 - Clear CMOS jumper
 - SPDIF-out connector
 - Serial port connector (COM2)
 - 2 x USB 2.0 connector support additional 4 ports
 - Front panel audio connector
 - Front panel connector
 - 1 x Floppy disk drive connector
 - 2 x Ultra DMA 133 IDE device connectors
 - 2 x Serial ATA device connectors

Back Panel I/O Ports

 - 1 x Parallel
 - 1 x Serial port (COM 1)
 - 1 x VGA
 - 1 x PS/2 Keyboard
 - 1 x PS/2 Mouse
 - 1 x Audio I/O (Line-in/Line-out/MIC)
 - 4 x USB 2.0
 - 1 x RJ45 LAN Jack
